ISR AQUA TREAT - INSTANT WATER PURIFIER

Crystal clear Iron & Bacteria Free Drinking water.
Retains thirst quenching test and important salts and minerals in water.
Saves fuel expenditure & electricity consumption.
Reduces detergent cost.
Supersedes hazardous candle filter technology.
Gives dazzling wash to your garments specially white clothing.
Keeps your skin & hair healthy.
Ensures good health & protects your family from many water born diseases.

FUNCTION
When the raw water passes through the spray nozzle the soluble part of iron get oxidized by the oxygen of air and converted into insoluble part. Then the water percolates through the charged catalytic media through the stage bed and insoluble iron gets precipitated.Then the water passes through silver coated activated carbon beds where due to surface activity some very small pores are there.
Here some bio turbidities get arrested. Finally the water goes through the micro net filter where the bacteria whose size is more than 0.3 micron get arrested. Thus the crystal clear iron and major harmful bacteria free filter water comes out through the outlet.

MAINTENANCE
Proper maintenance, viz. Rinsing.
Back washing Servicing gives better quality of water.
Once or twice back washing at regular interval ( 3 to 4 days ) is needed to clean the apparatus and increase its life.

PURPOSE
For best quality water without heat & electricity. Mainly used in Houses, Public places, Schools, Hospitals, Offices, Clubs, hotels, Industries, Labs, etc.

INDUSTRIAL DEMINERALISER PLANT

CAPACITY OF INDUSTRIAL D. M. PLANT
MODEL #
ISR-ID- 		CAPACITY
Ltr / Hr 		WORK PRESSURE
PSI
25
50
100
200
300
400
500
1000
2000 		250
500
1000
2000
3000
4000
5000
10000
20000 		20
30
40
40
40
40
50
50
60

Higher capacity is available as per requirement.
PURPOSE

For best distilled quality water without heat & electricity. Mainly uses in Pharmaceutical industries. Chemical Industries. Mirror Silvering, Power Stations, Research Labs, Food Processing, College Labs, Plastic Industries.

CONSTRUCTION
Two Ion exchange MSRL / FRP shell, one is Cation Exchanger and other is Anion Exchange fitted with MSRL / PVC pipe lines, valves, strainers and filled up with Cation and Anion Exchange Resigns and containing Acid and Alkali proof pots for regeneration.

OPERATION
In the simplest system the raw water flows successful through a Cation Exchanger regenerated with acid an Anion Exchanger regenerated with caustic soda. When the raw water passes through Cation Exchanger all the Cations are retained by the resin and there is no longer anything in the water but the acids of the salts it contained initially. Then the water passes through Anion Exchanger which absorbs the Acids and thus the D.M water is produced.

QUALITY OF D.M WATER
Purified water as per I.P conductivity -1 to 20 micro ohms/cm
pH of D.M water : Around 7.0 Storage Battery : IS : 1069 / 64


WATER SOFTNER

ISR INDUSTRIAL TYPE WATER SOFTNER

MODEL #
ISR-ID- 		FLOW RATE
Ltr / Hr 		WORK PRESSURE
PSI
1
2
3
4
5
6 		250
500
1000
2000
5000
10000 		20
30
30
40
50
50

Higher capacity is available as per requirement.

PURPOSE

For instant supply of soft filtered water without heat and electricity. Mainly used in Chemical Industries, Food Processing, Galvanizing, Research Labs, Power Stations, Cooling Towers, Domestic uses, A.C plant, Boilers, Heat exchanger, Chemical Plants, Tea Processing, Generating sets, Textiles Industries, Ice Factories, Breweries etc.

CONSTRUCTION
One mild steel rubber lined / PVC / FRP shell fitted with pipelines, valves, strainers, sampling cock, water meter and filled up with fully charged high capacity polyelectrolyte base Cation Exchange Resin, and containing one Acid proof pot for regeneration.

OPERATION
ISR water softener is manually operated Ion Exchange unit. When raw / iron free water passes through a bed of ion exchange resign in sodium form, the calcium and magnesium salts are taken up from the water by the cation exchanger, which simultaneously gives up an equivalent amount of sodium salts and thus the soft water is produced. Only common salt is required for regeneration.


DIFFERENTIAL PRESSURE TYPE CHLORINE DOSER

MODEL DOSER SIZE
( GALLON ) 		CAPACITY / HR
( GALLON )		 CAPACITY / CHARGE
( GALLON ) 		LIQ. CHLORINE
PER CHARGE 		DOSER PRICE LIQ. CHLORINE
PRICE
SCL - 1
SCL - 2
SCL - 3
SCL - 4
SCL - 5		 8
16
24
32
48 		500 - 5000
5000 - 10000
10000 - 15000
15000 - 20000
20000 - 30000 		100000
200000
300000
400000
500000 		1 LITRE
2 LITRES
3 LITRES
4 LITRES
5 LITRES

Higher capacity is available as per requirement.

HOW TO INSTALL & OPERATE
First connect the PVC tube with Valve # V1 & V2 on raw water pipeline as pipeline as per drawing. Open V5 & V6 and release the whole water from the vessel. Then close V5 & V6. Then open V3 & V4 and pour the chlorine soln. through the funnel as per chart. After pouring the chlorine soln. close V3 and open V2 until raw/filter water is filled up. As soon as the vessel is filled up with raw/filtered water, close V4 & V2 slowly for servicing. Take sample of water from the sampling cock for testing.

PURPOSE
For best quality of bacteria free water, without heat & electricity. Mainly uses in Hotels, Hospitals, Swimming Pool, Housing Flats, Tea Garden, P.H.E. Railways etc.

STANDARD DEMINERALISER PLANT

CAPACITY OF STANDARD D. M. PLAN
MODEL #
ISR-SD 		FLOW RATE
LTR / HR. 		CAPACITY
/ CHARGE
CHEMICAL REQUIRED
HCl (7-10%) NaOH (4-6%)
0
2
4
6
8
10

10
25
50
75
100
150

 80 L
200 L
400 L
600 L
800 L
1200 L 		1/2 Ltr
1 Ltr
2 Ltrs
3 Ltrs
4 Ltrs
6 Ltrs 		175 gms
350 gms
700 gms
1.0 Kg
1.3 Kg
2.0 Kg

Higher capacity is available as per requirement.

PURPOSE
For best distilled quality water, without heat & electricity. Used in Pharmaceutical industries. Chemical industries. Mirror silvering, Power stations, Research labs, Food processing, College labs, Plastic industries etc.

CONSTRUCTION
One Iron / Wooden frame embodying four wheels under carriage for easy movement. One Cation Exchange and one Anion Exchange charged into two PVC columns consequently filled by high capacity Cation & Anion Exchange resin and to maintain pH of water a buffer pot used. Acid & Alkali proof pots for regeneration.

OPERATION
In the simplest system the raw water flows successfully through a Cation Exchange regenerated with acid an Anion Exchange regenerated with caustic soda. When the raw water passes through Cation Exchanger all the Cations are retained by the resin and there is no longer anything in the water but the acids of the salts it contained initially. Then the water passes through Anion Exchanger which absorbs the Acids and thus the D.M water is produced.

QUALITY OF D.M WATER
Purified water as per I.P conductivity -1 to 20 micro ohms/cm
pH of D.M water : Around 7.0 Storage Battery : IS : 1069 / 64

PRESSURE FILTER

INDUSTRIAL TYPE VERTICAL & HORIZONTAL PRESSURE FILTER
Flow rate gallons per hour Working Pressure
100 GPH.
200 GPH.
500 GPH.
1000 GPH.
2000 GPH.
3000 GPH.
5000 GPH.
6000 GPH.
7500 GPH.
10000 GPH.
12000 GPH.
20000 GPH.
30000 GPH. 		15 Psi.
15 Psi.
20 Psi.
30 Psi.
30 Psi.
30 Psi.
40 Psi.
40 Psi.
50 Psi.
50 Psi.
60 Psi.
70 Psi.
70 Psi.

Higher capacity is available as per requirement.

PURPOSE

For instant supply of crystal Clear Filtered Water

CONSTRUCTION
Mild steel shell / FRP vessel, fitted with pipe lines, valves, strainers, sampling cock, pressure gauges and filled up with fully Charge of Graded Gravel and fittering media.

OPERATION
Pressure Filter is a manually operated sand filteration Unit. When raw water i.e., unfiltered water passes through a bed of filter media downwardly the suspended impurities is deposited on the Filter bed then the Filtered Water comes out. Only back-washing in necessary for cleaning the bed.

APPLICATIONS
Hotels, Hospitals, Swimming Pool, Housing Flats, Tea Garden, P.H.E. Railways etc.


CHEMICAL DOSER

Doser
Size in
Gallons 		Capacity
per Charges
in gallons 		Bleaching
powder is
required
per charge 		Soda ash is
required
per charge 		Sodium
hypochloride
is required
8
16
24
32
48 		50,000
1,00,000
1,50,000
2,00,000
2,50,000 		3 lbs.
6 lbs.
9 lbs.
12 lbs.
18 lbs. 		0.5 lb.
1.0 lb.
1.5 lbs.
2.0 lbs.
2.5 lbs.
 1 Litre
2 Litres
3 Litres
4 Litres
5 Litres

Higher capacity is available as per requirement.

PURPOSE
For Instant Supply of desired quality of water.

OPERATION
Displacement type chemical doser provide simple and effective means of adding chemical solution to water flowing through the pressure main.

APPLICATIONS
Hotels, Hospitals, Swimming Pool, Housing Flats, Tea Gardens, P.H.E., Railways. etc.


ACTIVATED CARBON FILTER

Capacity Working Pressure
75 GPH.
100 GPH.
150 GPH.
250 GPH.
400 GPH.
500 GPH.
750 GPH.
1000 GPH.
3000 GPH.
5000 GPH.
6000 GPH.
7000 GPH.
10000 GPH.
20000 GPH. 		15 Psi.
15 Psi.
20 Psi.
20 Psi.
20 Psi.
20 Psi.
30 Psi.
30 Psi.
40 Psi.
40 Psi.
50 Psi.
50 Psi.
60 Psi.
70 Psi.

Higher capacity is available as per requirement.

PURPOSE
For Instant supply of Chlorine & Organic Matter free Filtered Water

CONSTRUCTION
Mild steel shell / FRP vessel, fitted with pipe lines, valves, strainers, sampling cock, pressure gauges and filled up with full charge of Activated Carbon.

APPLICATIONS
Soft Drink Unit, Food Processing Unit, Breweries, Effuluent Treatment, etc. etc.

OPERATION
A.C. Filter is a manually operated carbon filteration Unit when raw water i.e, untreated water passes through a bed of activated Carbon down wardly, the organic substances is deposited on the bed and then treated water comes out. Only back washing is necessary for cleaning the bed.


IRON REMOVAL FILTER

Flow rate gallons/hr Working Pressure
50 GPH.
100 GPH.
150 GPH.
250 GPH.
400 GPH.
600 GPH.
1000 GPH.
2000 GPH.
3000 GPH.
5000 GPH.
6000 GPH.
7500 GPH.
10000 GPH.
20000 GPH. 		15 Psi.
15 Psi.
15 Psi.
15 Psi.
20 Psi.
20 Psi.
30 Psi.
30 Psi.
30 Psi.
40 Psi.
50 Psi.
50 Psi.
60 Psi.
60 Psi.
Higher capacity is available as per requirement.

PURPOSE
For Instant Supply of Iron Free Filtered Water.

CONSTRUCTION
Mild steel shell / FRP vessel, fitted with pipe lines, valves, strainers, sampling cock, pressure gauges and filled up with full charge of Filtering Media.

OPERATION
Iron Removal Filter is manually operated Catalytic Filtration unit when raw water i.e., unfiltered water passes through a bed of Catalytic media, the dissolved Iron in ferrous form is converted into Ferric state and precipitated inside the bed and then the filtered water comes out. Only back washing is necessary for cleaning the bed.

APPLICATIONS
Hotels, Hospitals, Swimming Pools, Housing, Tea Gardens, P.H.E., Railways etc.
